DV715B OPERATION
SWC Input Operation
The
built-in SWC Interface is compatible with PAC steering wheel control modules.
The PAC SWI-RC is recommended. A third-party adapter must be used in order for
the DV715B to be compatible with any steering wheel controls. The following controls
are available for most vehicles.
1. Volume Up (+) 4. Preset (+) 7. Seek/Track Up (+) 10. BT Talk
2. Volume Down (-) 5. Preset (-) 8. Seek/Track Down (-) 11. BT End
3. Mute 6. Mode 9. Band
Note: Not all OE steering wheel functions may be supported by the DV715B.
PAC SWI-RC Installation Hints
1. Set "Radio Select Switch". Set the SWI-RC to position 7 - "Pioneer/Other/Sony".
2. To program, use the Pioneer/Sony/Other radio function mapping order for Dual
units.
3. When programming the SWI-RC, if a function is not supported (or not desired), then
the
function MUST be skipped as per the PAC SWI-RC instructions.
Func-
tion
Order
Function
Mapping
SWI-RC (3.3VDC Reference)
Center Pin (Ring) Volt-
age
(Function Select)
Tip Pin Voltage
1 Volume + H 5.0v 2.07
2 Volume - H 5.0v 2.32
3 Mute H 5.0v 1.01
4 Preset + L 0.0V 1.54
5 Preset - L 0.0V 1.81
6 Source H 5.0v 0.60
7 Seek + / Track + H 5.0v 1.54
8 Seek - / Track - H 5.0v 1.81
9 Band H 5.0v 2.73
10 BT Talk L 0.0V 0.60
