5
Before You Start
•
Disc
onnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or
where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Insert the supplied keys into the slots as shown, and slide the unit out of the mounting sleeve.
•
Ins
tall mounting sleeve into opening, bending tabs to secure.
• Connect wiring harness as shown on page 6. Consult a qualified technician if you are unsure.
•
Cert
ain vehicles may require an installation kit and/or wiring harness adapter (sold separately).
• Reconnect negative battery terminal, and test for correct operation.
•
Snap trim ring into place (if required).
• Slide unit into mounting sleeve to secure.
DV715B INSTALLATION
Preparation
Mounting sleeve opening dimen-
sions
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
