Dual X2DMA400 - Control Locations - Receiver

4
X2DMA400 OPERATION
Control Locations - Receiver
Source/Power( )
Eject
Mute/Tag
Display
Volume Knob
Back/Band
Select
Audio/Menu
TuningKnob
AuxiliaryInput
SDCardSlot
1
2
3
4
5
6
USBPort
Preset6/FolderUp
Preset5/FolderDown
Preset4/Play/Pause
Preset3/Intro
Preset2/Random
Preset1/Repeat
Tune/TrackUp
Reset
Tune/TrackDown
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
3 5 84
9
6 7
19
20
21
18 1617 11 10
15
14
12
13
21
