Dual XDM17BT User Manual

10
XDM17BT OPERATION
Specifications
Tuning range: 87.5MHz-107.9MHz
Usable sensitivity: 8.5dBf
50dB quieting sensitivity: 10dBf
Stereo separation @ 1kHz: >30dB
Frequency response: 30Hz-13kHz
Tuning range: 530kHz-1710kHz
Usable sensitivity: <42dBu
Frequency response: 30Hz-2.2kHz
Speaker output impedance: 4~8 ohms
Line output voltage: 2 Volts RMS
Dimensions: 7" x 2" x 2" (178 x 50 x 50 mm)
Design and specifications subject to change without notice.
FM Tuner
AM Tuner
General
CEA-2006 Power Standard Specifications
(reference: 14.4VDC +/- 0.2V, 20Hz~20kHz)
Power Output: 14 Watts RMS x 4 channels at 4 ohms and < 1% THD+N
Signal to Noise Ratio: 75dBA (reference: 1 watt into 4 ohms)

Dual XDM17BT Specifications

General

Bluetooth	Yes
Preamp Outputs	Yes
USB Port	Yes
Auxiliary Input	Yes
AM/FM Tuner	Yes
USB Input	Yes
AUX Input	Yes
Display Type	LCD
Radio Tuner	AM/FM
Display	LCD
Power Output	200 Watts
Peak Output	50W x 4
DIN	Single DIN
