3
XDM17BT INSTALLATION
Wiring Diagram
FUSE
When replacing the
fuse, make sure new
fuse is the correct type
and amperage. Using
an incorrect fuse could
damage the radio.
The unit uses
one 10 amp AGC fuse
located beside
the Heat Sink
10 AMP
AGC Fuse

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dual XDM17BT and is the answer not in the manual?

Dual XDM17BT Specifications

General IconGeneral
BluetoothYes
Preamp OutputsYes
USB PortYes
Auxiliary InputYes
AM/FM TunerYes
USB InputYes
AUX InputYes
Display TypeLCD
Radio TunerAM/FM
DisplayLCD
Power Output200 Watts
Peak Output50W x 4
DINSingle DIN
