Power and Speaker Connections
Ground Connection
RemoteConnection
+12VDCBatteryConnection
1
2
3
Fuse(s)
SpeakerConnection(s)
4
5
5
XPR522
1
32 5
4
1
32
5
4
XPR522
XPR540
