Dual XR4110 User Manual

5
General Operation
Press to turn the unit on. Press and hold for more
than two seconds to turn the unit off.
Press SOURCE to select between AM/FM, auxiliary input,
USB or SD Card modes. Modes of operation are indicated in
the display. SD and USB modes will not appear unless an
SD Card or USB device is connected.
Press and hold LOUD for more than 2 seconds to activate
anddeactivatetheloudnessfeature.Activatingthisfeature
willenhancethebassandtreblefrequencieswhenlistening
to music at low volumes.
Inserta3.5mmconnectorinthefrontpanelAUXport.
Connecttheotherendofthe3.5mmconnectortothe
headphone output of an audio device, MP3 player, etc.
Adjustvolumeusingthe volume knob(00-42).
Press AUDIOtoselectbetweenBass,Treble,Balanceand
Fader.
Press AUDIO until BASS appears
Rotate the volume knobleft/righttoadjust
(-7minimum/7maximum)
Press AUDIO until TRE appears
Rotate the volume knobleft/righttoadjust
(-7minimum/7maximum)
Press AUDIO until B 00 appears
Rotate the volume knobleft/righttoadjust
BL 15(left)toBR 15(right)
Press AUDIO until F 00 appears
Rotate the volume knobleft/righttoadjust
FR 15(rear)toFF 15(front)
Press EQ for more than two seconds to activate the first
preset EQ, then press and hold EQagaintoselectbetween
POP,CLASSIC,ROCKandUSER.Manualadjustmentstothe
bassandtreblesettingsaresavedasUSER.
Power On/Off
Source
Loud
Auxiliary Input
Volume
Select Audio
Bass
Treble
Balance
Fader
Preset EQ Curves
XR4110 OPERATION
BASS
TREBLE
BALANCE
FADER
