DualLite LSN - Parameter Management and Operating Modes

24
201.1 Using The Interface Panel
The User Interface Panel is used to display over 250 system parameters, operating modes, alarms and stored logs.
When the correct password is entered, the user can also change system modes and parameter values.
Ifthewrongkeyispressedatanytime,press(CLR)andthenthecorrectkey.Thecontrolpanelwillbeepeachtime
you press a key.
Before changing parameter settings or system modes, a user password must be entered. User password consist of
six,userselected,numericdigits.Theuserpasswordisstoredinparameter178andcanbeuserdenedbyfollowing
the "How To Change A Parameter Value" in Section 200.2.3
201.2 How To Display A Parameter
1. Press [DSP]
2. Enter the desired parameter number
3. Press [ENT]
Forexample,todisplayparameter7(BatteryVolts&ChargingCurrent),followthesesteps:
User Keypad Actions Display Readout
[DSP] Enter Display Code
setup value
7 Enter Display Code
setup value 7
[ENT] MoreBatteryMeterFunctions(5)
Battery 108.2 V, BattIin 1.2 A
201.3 How To Clear A User Password
Once a password has been entered, it can be cleared in one of the two following ways:
1. If the User Interface Panel remains inactive for a period of 30 minutes, the password will be automatically cleared.
2. Press [PRG] 233 to display the password parameter menu. The display will present prompt "1" to cancel all
passwords. Press 1, [ENT] to clear password.
201.4 How To Change A Parameter Value
NOTE: Only certain parameters are user changeable. Refer to the complete parameter listings on the following
pages; user changeable parameters are shown in boldface.
1. Press [PRG]
2. Enter the desired parameter number
3.Entertheuserpassword(ifnotalreadyactive)
4. Press [ENT]
5. Enter the new parameter value and press [ENT]
For example,tochangeparameter0(time)to9:30a.m.,followthesesteps:
