Ducati Monster 620DARK - Key-Operated Ignition Switch and Steering Lock (Fig. 10); LH Switch

E
18
Key-operated ignition switch and steering lock
(fig. 10)
It is located in front of the fuel tank and has four positions:
A) ON: lights and engine on;
B) OFF: lights and engine off;
C) LOCK: steering locked;
D) P: parking light and steering lock.
Note
To move the key to the last two positions, press it
down before turning it. Switching to (B), (C) and (D), you
will be able to take the key out.
LH switch (fig. 11)
1) Dip switch, light dip switch, two positions:
position = low beam on;
position = high beam on.
2) Switch = 3-position turn indicator:
centre position = OFF;
position = left turn;
position = right turn.
To cancel turn indicators, push in once switch returns to
central position.
3) Button = warning horn.
4) Button = passing.
fig. 10
fig. 11
