MAIN COMPONENTS AND DEVICES
Position on the vehicle (fig. 19)
1) Tank filler plug
2) Seat lock
3) Helmet cable pin
4) Passenger grab rail
5) Side stand
6) Rear-view mirrors
7) Rear shock absorber adjusters
8) Tank prop rod
9) Seat cover (apart from 620DARK)
10)Tank fastening lever
11)Catalytic converter
1
10
7
8
2
9
3
5
4
9
6
11
fig. 19
