Ducati Monster 795 - Refitting the Battery

Refitting the battery
Important
When battery must be refitted, ALWAYS
contact a Ducati Dealer or authorised Service Centre.
Install the battery in the battery mount and secure it
with the elastic retaining strap (19).
Connect the positive cable (20) to the positive
terminal and the negative cable (21) to the negative
terminal, as shown in the figure. Insert the screws
(22) in the terminals (20) and (21), always starting with
the positive terminal (red cable).
Warning
Position the cables (20) and (21) as shown in the
figure.
Tighten the screws (22) to a torque of 10 Nm ± 10%.
Apply grease around the battery terminal clamps to
prevent oxidation.
22
21
19
20
Fig. 78
110
