Adjusting the position of the gearchange
and rear brake pedals
The gear change and rear brake pedals can be
adjusted to suit the preferred riding position of each
rider.
To adjust the position, proceed as follows: hold the
rod (1) and slacken the counter nuts (2) and (3).
Note
Nut (2) has a left-hand thread.
Turn the rod (1) using an open-ended wrench on the
flats to move the gear change pedal to the required
position.
Tighten both counter nuts onto the rod.
