Ducati Monster 795 - Instrument Panel Diagnostics

Instrument panel diagnostics
Important
The instrument panel runs system diagnostics
after 60 seconds from the last Key-Off.
This function allows you to display and identify
malfunctions of the motorcycle and, where possible,
renew components identified as faulty.
To view this function, access the "Error" page of the
menu.
This menu is only active when at least one error is
present, otherwise the page will NOT appear.
If more errors are present, they are displayed one by
one every 3 seconds.
In any case, a more detailed diagnosis can be
obtained using the Ducati Diagnostic System.
Warning
When an error is displayed, always contact a
Ducati Dealer or authorised Service Centre.
"WARNING LIGHT / ERROR" MES-
SAGE
ERROR
TPS 01 Throttle potentiometer D.C. Vdc or A.c.
TPS 01 Throttle potentiometer D.C. GND
PRESS 02 Pressure sensor D.C. Vdc
PRESS 02 Pressure sensor D.C. GND or A.c.
OIL 03 Oil NTC sensor D.C. Vdc or A.c.
51
