Ducati MULTISTRADA 1260 - Front Mudguard Half Kit

Front mudguard half kit
Important
To fit the front semi-mudguard kit, ALWAYS
contact a Ducati Dealer or Authorised Service Centre.
Remove the pipe grommet (1) from mudguard (6)
unscrewing the two screws (2).
Position the front semi-mudguard kit (3) on the front
mudguard (6), housing the front brake pipe (4) and the
front phonic wheel cable (5) as shown in the figure
(Fig. 290).
To position the front semi-mudguard kit (3), insert the
tabs (A) in the front mudguard (6) seat.
1
6
2
Fig. 289
5
3
6
4A
5
4
Fig. 290
336
