2. TECHNICAL
80 radio zones – Each zone can store one detector
9 remote controls for arming/disarming the receiver and drive the arming output (COM-NC-NA)
8 relay outputs for alarm from radio zones (not from remote controls)
Each output is combined to one group of 10 radio zones (eight groups)
Relay data: 24 V / 500 mA
Activation type: impulsive, aperture time > 2 seconds
Warning: the outputs always change status when an alarm from radio zones is received, even if the
receiver is disarmed (only in PARTIAL arming the radio zones 61 ÷ 80 are disabled and thus the outputs
7 and 8 are disabled too)
1 relay output (dry contact) for arming/disarming command from remote controls
Relay data: 24 V / 500 mA
Activation type: bistable (> 2 s) or impulsive
1 relay output for radio-blinding, sensor masking, wired and radio tamper
Relay data: 24 V / 500 mA
1 OpenCollector output for low battery of radio zones (zone showed on display) or radio-blinding
1 OpenCollector output for Supervision or Partial arming of receiver
1 OpenCollector output for armed status of receiver (TOTAL or PARTIAL)
Programming menu
Zones, arming status and alarm memory
Opened door (only for radio detectors compatible with Opened Doors function)
9 ÷ 14 V (typical: 12 V ) / MAX 60 mA
WARNING > The device must be supplied by low voltage power source (SELV)
Compatible with:
All AN detectors
The receiver visualize on display detailed information from special radio sensors:
o CTSR: on-board reed/internal contact, secondary contact, roller, shock sensor
o MINI-C: on-board reed/internal contact, secondary contact, roller, shock sensor
o MOSKITO-R: right side, left side, center, elusion
Remote controls: TXS/M, TXS4, TX2C
Antimasking signalling from sensors: MOSKITO, VIPER, VIPER-DT and KAPTURE
