Dufour 530 - Principal Specifications

ENGLISH 28-04-2020 10/97 DUFOUR 530
II. PRINCIPAL SPECIFICATIONS
Model:
DUFOUR 530
Constructor
Dufour
11, Rue Blaise Pascal
17187 Périgny cedex
FRANCE
Architecture:
Umberto Felci
Interior design
DUFOUR Design
Yacht design category
A
No. of the notified body
CE/0607
CIN No.
Primary means of propulsion
Sail
L
max
Length overall *
16.35 m
L
H
Hull length*
15.50 m
B
max
Maximum beam*
4.99 m
B
H
Hull beam*
4.99 m
H
A
Maximum air draft*
23.25 m
T
max
Draft (Shallow / deep keel / VDD) *
2.05 / 2.40 / 2.90 m
Keel weight (shallow / deep / VDD)
4950 / 4700 / 4600 kg
Standard mainsail area (approx.)
65 m²
Self-tacking jib area (approx.)
45 m²
Maximum permissible on-board engine power
110 CV / 81 kW
Water capacity excl. 60 L (approx.) water heater
680 L
Diesel capacity (approx.)
430 L
Holding tank – depending on the version
Up to 235 L
Engine battery
105 Ah
Auxiliary battery (optional)
Minimum 560 Ah
* The above specifications comply with ISO 8866, i.e.:
L
max
: maximum length of the boat including normally fixed parts such as bow rollers, pulpits, etc.
L
H
: maximum length of the vessel including structural elements that are an integral part of the
vessel, and excluding removable parts.
B
max
: breadth of the vessel measured between the outermost portions, which may include
detachable parts such as top rails, railings, etc.
B
H
: breadth of the vessel measured between the outermost fixed portions and excluding all
removable parts
H
A
: vertical distance between the unladen water line and the highest point of the mast structure.
(this does not take into account equipment such as lights and antennas that may be attached to
the masthead)
T
max
: the maximum draft is measured at the lowest point of the boat’s keel under maximum load
conditions
N.B.: due to the trim and load of the boat, it is not usually possible to use all the various
tank capacities for fresh water and diesel. It is recommended that you maintain a diesel
reserve of 20%.
