Dufour 530 - Skin Fitting Location Diagram

ENGLISH 28-04-2020 81/97 DUFOUR 530
21. Skin fitting location diagram
Label
Description
Ø
1
Galley sink discharge
1‘’ 1/4
2
Washbasin + shower discharge
1’’
3
Toilet sea-water intake
3/4'’
4
Toilet discharge
2’’
5
Exterior sink discharge*
1’’
6
Seawater pump intake
1/2’’
7
Water separator outlet – Generator*
1’’
8
Footbath discharge (3)
2’’
9
Electric bilge pump discharge
1’’
10
Manual bilge pump discharge
1’’
11
Seawater intake – A/C*
3/4'’
12
Seawater intake – Desalination unit*
1/2’’
13
Seawater intake - Generator*
3/4'’
14
Seawater intake – D3 -110 engine*
1’’ 1/4
*
Option
