Dufour 530 - Circuit Diagram with Options

ENGLISH 28-04-2020 51/97 DUFOUR 530
8. 220V circuit diagram with options
Label
Description
Facilities
A
220V Shore cable**
B
Shore connection
C
Electrical cabinet with main circuit breaker 32A
D
Thruster charger (bow and stern)*
E
Watertight dishwasher or washing machine socket*
F
Dishwasher*
G
Washing machine*
H
Air conditioner*
I
Desalination unit*
J
220V cabinet connector
K
220V cabinet
M
Electrical cabinet with main circuit breaker 50A*
N
Source Selector*
O
Electrical cabinet with differential circuit breaker 32A –
30 mA*
P
Inverter*
Q
Generator*
R
Generator control panel*
S
Combi Quattro control panel*
T
12V/220V/3000W Combi Quattro*
U
Auxiliary battery installation
V
500A fuse*
W
A/C circuit breaker cabinet*
X
Optional circuit breaker cabinet*
Y
Generator ground plane*
Z
Engine battery
Electrical wiring colours
b
Light blue
g
Green
m
Brown
n
Black
r
Red
v
Green/yellow
w
White
*
Option
**
Not supplied
