3. Deck fittings layout
LABEL
DESCRIPTION
REMARKS
A
JACKLINE ANCHOR POINTS
Port and starboard
cleats
B
TOWING POINTS
PT/STBD
C
IT IS OBLIGATORY TO KEEP THE HATCHES CLOSED
WHEN SAILING
D
"MAN OVERBOARD" REBOARDING LADDER
E
LIFER AFT STOWAGE
F
LOCKER MUST BE CLOSED WHEN UNDERWAY
1
BOW ROLLER
2
FOLDING PAD EYE D8
3
FOLDING PAD EYE D8
Furling line
4
FOLDING PAD EYE D8
Spinnaker option
5
FOLDING PAD EYE D8
Standard GV
6
DOUBLE FOLDING PAD EYE D8
Releasable forestay
option
7
WATERPROOF PAD EYE D10
8
SINGLE CLUTCH
Furling line
9
SINGLE CLUTCH
Spinnaker option
10
SINGLE CLUTCH
Genoa option
11
SINGLE CLUTCH
Standard pack
12
TRIPLE CLUTCH
Standard pack
13
TRIPLE CLUTCH
Navigation+ pack
14
5-SHEAVE DECK ORGANIZER
15
SIMPLE PULPIT
16
PORT PUSHPIT
17
STARBOARD PUSHPIT
18
MIDSHIP PUSHPIT
19
SWIMMING LADDER
20
COACH ROOF GRAB RAIL
21
FUEL DECK PLATE
22
SELF-TACKING JIB TRACK
23
GENOA TRACK
Option
24
MAINSHEET TRACK
Navigation+ pack
25
ALUMINUM MOORING CLEAT
26
COAMING WINCH
27
HELMSMAN WINCH
28
ROOF WINCH
