10. Fuse location diagram
Label
Description
A
Zone A - 24 V
Strip fuse 325A: optional bow thruster*
Thermal circuit breaker 110A: windlass
B
Zone B - 220 V
Ph/N circuit breaker 10A: dishwasher option*
Ph/N circuit breaker 10A: washing machine option*
Ph/N circuit breaker 10A: aft thruster charger option*
Differential circuit breaker 16A/30mA: inverter option (32A/30mA at 110V) *
Single-pole/Neutral circuit breaker 16A: desalination unit protection*
Differential circuit breaker 32A/30mA: A/C option*
Double-pole D-curve circuit breaker 16A: forward A/C option (20A at 110 V) *
Double-pole D-curve circuit breaker 16A: aft A/C option (20A at 110 V) *
Double-pole D-curve circuit breaker 20A: saloon A/C option w/o Pullman cabin (40A at
110V) *
Two double-pole D-curve circuit breakers 10A and 16A: A/C option with Pullman cabin
(16A and 20A at 110V*)
Zone B - 12 V
Type-C circuit breaker 63A: desalination unit option*
C
Zone C - 220 V
Differential circuit breaker 16A/30mA: TV option*.
Zone C - 12V
Type-C circuit breaker 16A: Electric toilet option*
D
Zone D - 12V
200A strip fuse: Panel protection
160A strip fuse: Inverter protection*
500A strip fuse: Quattro protection*
E
Zone E - 12V 6-module electrical box
Blade fuse 40A: auto pilot option*
Blade fuse 1A: heating option (x4)*
Blade fuse 3A: heating option
Blade fuse 5A: windlass
Strip fuse 400A: stern thruster option*
Strip fuse 80A: generator*
F
Zone F - 12V
Blade fuse 10A: Noval gate*
Auxiliary battery info soapstone fuse 8A
Engine battery info soapstone fuse 8A
G
Zone G - 12 V
Single-pole circuit breakers 110A: Port and starboard electric coaming winch option*
Single-pole circuit breakers 110A: Port and starboard electric helmsman winch option*
Single-pole circuit breakers 110A: Port and starboard electric roof winch option*
Blade fuse 10A: Bilge fan
H
Zone H - 24 V
Strip fuse 325A: Stern thruster option*
Zone H - 220 V
Differential circuit breaker 32A: General generator protection*
I
Zone I - 220 V
Double-pole circuit breaker 32A: General shore protection
Double-pole circuit breaker 50A: General protection A/C option*
J
Zone J - 12 V
Strip fuse 80A: GE option*
