Dufour 530 - Gas System Diagram

ENGLISH 28-04-2020 72/97 DUFOUR 530
17. Gas system diagram
No.
Description
1
Gas cylinder**
2
Cylinder shut-off valve
3
Low-pressure regulator + pressure gauge
4
0.6m G1/4 hose – D8 tube
5
Brass elbow bulkhead for the D8 tube
6
6x8 copper tube
7
T-shaped olive connector*
8
Black PVC sheath (protection)
9
PVC tube (protection)
10
G1/4 quick-closing valve – D8 tube
11
G1/4 – G1/4 1m hose
12
G1/4 – G1/4 1m hose*
13
Cooker/Oven
14
Built-in foldaway
X
6x8 insert / tube
*
Option
**
Not supplied
