Dufour 530 - Freshwater System Diagram

ENGLISH 28-04-2020 77/97 DUFOUR 530
19. Freshwater system diagram
Label
Description
1
Filler deck plate
2
Filler hose
3
Vent
4
Vent hose
5
6
Fore water tank, 280 L
Saloon water tank, 200 L (x2)
7
Hot water pipe
8
Cold water pipe
9
Pressurized water pump unit
10
Fresh-water pump
11
Water heater
12
Head shower single-lever mixer tap
13
Galley single-lever mixer tap
14
Deck shower
15
Bathroom single-lever mixer tap
16
1/2" 3-way manifold
17
3/4"-1/2” MF reducer
18
1/4 turn FF 1/2” valve
19
3/4" WX F connector
20
21
22
23
24
1/2" WX M connector
Washing machine connection*
Exterior sink mixer tap*
Deck seawater intake*
Shower mixer tap
*
Option
