22. Mechanical installation diagram
Label.
Description
1
Locknut 7/16 UNF*
2
Hex screw 7/16 UNF*
3
D35 stern gland*
4
Volvo D3 -110 HS63IV engine*
5
Rubber bellows*
6
48-54 stern tube*
7
D35 propeller shaft*
8
D35 bracelet*
9
D35 cutlass bearing*
10
D35 shaft bracket*
11
D35 tightening flange*
12
Stainless steel exhaust elbow*
13
D3-110 polyester chassis*
14
3P MaxProp propeller*
15
D2-75 polyester chassis
16
VOLVO D2-75 – 150S engine
17
Engine foam insulation
18
VOLVO D90 waterlock
19
Type-V anti-siphon elbow
20
1’’ 1/4 strainer skin fitting*
21
1/4T 1’’1/4 seacock*
22
D3-110 exhaust pipes*
23
D3 -110 seawater pipes*
24
D2 -75 exhaust pipes
25
D2 -75 seawater pipes
26
D100 plastic elbow section
27
Starter battery
28
Battery isolator
29
D90 exhaust outlet
30
1’’1/4 seawater filter
31
Morse steering box
32
2.5’’ engine screen*
33
Engine control box*
34
Rev counter
35
Engine control panel
*
Option
