Dufour 530 - Charging and Power System Diagram

ENGLISH 28-04-2020 57/97 DUFOUR 530
11. Charging and power system diagram
Label
Description
A
Windlass
B
Windlass control (remote)
C
D
Windlass remote control relay
Fuse 8A: engine test
E
Charger
F
12 V distribution panel
G
Single-pole 110 A windlass circuit breaker
H
Auxiliary batteries
I
Fuse 200 A (auxiliary)
J
Auxiliary batteries switch
K
5 A fuse
L
Alternator
M
Distributor
N
Starter
O
Engine battery
P
Engine battery isolator
Q
Windlass relay
R
Bilge fan relay
S
5 A fuse
T
Bilge fan
U
Windlass battery isolator
V
Windlass fuse 160A
W
Windlass charger
X
Windlass battery
Y
EVC VOLVO relay
B-
Bolt - (electrical panel)
B+
Bolt + (electrical panel)
MM-
Engine earth
