Dukane Infinity Series - Infinity Generator Number Guide

403-618-03 Infinity™ Series Servo Ultrasonic Press Systems User Manual
81
SECTION 7 | SPECIFICATIONS
Example 1: Part Number: 20HS360-2Y-C2-S-N0
Description: 20 kHz horizontal bench generator, 3600 W, 200-240 VAC, for Infinity™ servo press with Ethernet/IP support, and no option card support.
Example 2:
Part Number: 30HS120-UY-C2-S-N0-AA01
Description: 30 kHz horizontal bench generator, 1200 W, 100-240 VAC, for Infinity™ servo press with Ethernet/IP support, no option card support, with
customization 01 for customer AA.
Infinity™ Generator Number Guide
20
Nominal U/S
Frequency
15 = 15 kHz 20 = 20 kHz 25 = 25 kHz 30 = 30 kHz 35 = 35 kHz 40 = 40 kHz 50 = 50 kHz 70 = 70 kHz
Power Level
500 = 5000 W 360 = 3600 W 260 = 2600 W 180 = 1800 W 120 = 1200 W 090 = 900 W 070 = 700 W 060 = 600 W
AC Line Input
2 = 200-240 VAC (1800 W to 5000 W)
Standard PFC for 2600W and below.
High power PFC for above 2600W.
4 = 480 VAC Three-Phase U = 100-240 VAC universal voltage input
(1200W and below)
360
Front Panel
Y = LCD Display
Communications Bus
C0 = No Communication Bus Support C2 = Ethernet/IP Support Enabled C3 = iQLinQ™ PROFINET Interface Module C4 = iQLinQ™ CC-Link Interface Module C5 = iQLinQ™ POWERLINK Interface Module C6 = iQLinQ™ EtherCAT Interface Module
2
Y
C2
S
Option Slot
N0 = No Option Card Support X1 = SynQro Leader X2 = SynQro Follower
-
N0
Press Type
S = Servo
Note: Not all combinations are possible or available.
Chassis
Orientation
HS = Horizontal VS = Vertical
HS
- --
-XX##
Customization
Blank = No Customization XX = Customer Abbreviation ## = Customization Code
Innity™ Generator Number Guide
Table 7-3 
