403-618-03 Infinity™ Series Servo Ultrasonic Press Systems User Manual
79
SECTION 7 | SPECIFICATIONS
Thruster Model
Stroke
Maximum
Weld Force
Maximum Speed
Linear Encoder
Resolution
Maximum Horn
Weight
in mm lbs N in/s mm/s in um lbs kg
43NTX1N
3.5 89 150 670 7.5 190 0.00004 1.0 4.0 1.8
43NTX1S
3.5 89 150 670 13.8 350 0.00004 1.0 4.0 1.8
43NTX2N
5.0 127 550 2450 4.3 110 0.00004 1.0 25 11.4
43NTX3N
5.0 127 550 2450 4.3 110 0.00004 1.0 25 11.4
43NTX4N
5.0 127 1000 4450 4.3 110 0.00004 1.0 60 27.3
Table 7-1
Operang Environment
Operate the equipment within these guidelines:
Temperature:
Air Parculates:
Humidity:
Non-operating storage guidelines:
Temperature:
Air Parculates:
Humidity:
Thruster Specifications
