Dukane Infinity Series - Operating and Safety Switch Details; E-Stop (Abort) Switch Details

403-618-03 Infinity™ Series Servo Ultrasonic Press Systems User Manual
63
SECTION 5 | CONTROLS AND INDICATORS
Operang / Safety Switch Detail
E-Stop Switch Detail
Figure 5-4
Figure 5-3
PUSH TO
ACTIVATE
TWIST CLOCKWISE TO RELEASE
RED
STATUS LED
GREEN
POWER LED
ACTIVATION AREA
