SECTION 7 | SPECIFICATIONS
403-618-03 Infinity™ Series Servo Ultrasonic Press Systems User Manual
82
Table 7-4 
Innity™ System Number Guide
Example: 2026.2Y.C3-X3N.2R Description: A 20 kHz 2600 Watt Infinity™ generator with a 220/240 VAC line cord and PROFINET communications module, a 20K Infinity™ standard servo press on a rigid support and a 220/240 VAC line cord.
20
Nominal U/S
Frequency
15 = 15 kHz 20 = 20 kHz 30 = 30 kHz 35 = 35 kHz 40 = 40 kHz 50 = 50 kHz 70 = 70 kHz*
Power Level
50 = 5000 W 36 = 3600 W 26 = 2600 W 20 = 2000 W 18 = 1800 W 12 = 1200 W 09 = 900 W* 07 = 700 W* 06 = 600 W
Generator AC Line
1 = 110/120 VAC 2 = 220/240 VAC 4 = 380/480 VAC (Three-Phase) E = 220/240 VAC (Europe) N = 220/240 VAC (India) C = 220/240 VAC (China)
26
Generator Type
Y = Infinity™ Horizontal V = Infinity™ Vertical
Generator Communications Options
C0 = No Communication Bus Support C2 = Ethernet/IP Support Enabled C3 = iQLinQ™ PROFINET Interface Module C4 = iQLinQ™ CC-Link Interface Module C5 = iQLinQ™ POWERLINK Interface Module C6 = iQLinQ™ EtherCAT Interface Module
.
2
Y
.
C3
X3
.
R
XX##
Press Options
N = None (Standard) S = High Speed F = High Force
Support Options
R = Rigid Infinity™ Support (X1, X3, and X4) S = X2 Rigid Support U = X2 Round Column Support 4 = X2 Round Column Support, 4 ft. 5 = X2 Round Column Support, 5 ft. 6 = X2 Round Column Support, 6 ft. LR = Less Base for X1, X3, and X4 LS = Less Base for X2 Rigid Column LU = Less Base for X2 Round Column L4 = Less Base with 4 ft. Round Column L5 = Less Base with 5 ft. Round Column L6 = Less Base with 6 ft. Round Column T = Thruster Only
Customization
Blank = No Customization XX## = Customization Code
-
-
2
Press AC Power Cord
1 = 110/120 VAC 2 = 220/240 VAC E = 220/240 VAC (Europe) N = 220/240 VAC (India) C = 220/240 VAC (China)
N
Press Size
X1 = Mini Infinity™ Servo (Requires 10 Amp AC Line) X2 = 20K Slim Infinity™ Servo (Requires 10 Amp AC Line) X3 = 20K Infinity™ Servo (Requires 10 Amp AC Line)
X4 = 15K/Super 20K Infinity™ Servo (Requires 10 Amp AC Line)
Note: Not all combinations are possible or available. * = Consult Marketing
