Duke FBB-10-230 - Adjustments At Installation; Raise Or Lower Broiler

9
Installation & Operation Manual for Flexible Batch Broiler - CE Units
Thebroilerheightcanbeadjustedviatwoscrewson
eachleg.
Caution: The Broiler is very heavy!
Use adequate help for lifting.
1. Liftoneendofthebroilerontoawide,sturdystand
(notsupplied).
2. Remove (2) screws per leg and raise/lower to
threadedholes.Reinstallscrews.
3. Removestandandsafelyraise/lowerbroiler.
4. Placeplasticholeplugs(suppliedattachtostand)
inanyunusedholes.
D. ADJUSTMENTS AT INSTALLATION
Eachbroilersectionandallitscomponentpartshave
beentestedthoroughlyandinspectedbeforeyourbroiler
wasshippedfromthefactory.However,itissometimes
necessarytofurthertestoradjustthebroileronceithas
beeninstalled.Suchadjustmentsaretheresponsibility
oftheDealerorInstaller.Thesetypesofadjustments
arenotconsidereddefects,ratheranormalandroutine
partoftheproperinstallationoftheequipment.
Theseadjustmentsincludebutarenotlimitedto:
•Adjustmentstothegaspressureregulator
•Broilerheightadjustment(ifrequired)
No installation should be considered complete
withoutproperinspectionand,ifnecessary,any
adjustments by qualified service or installation
personnel.
It is alsoimportantnot to obstruct the natural ow
ofcombustionandventilationair ifthebroiler isto
operateproperly.Thisbroilershouldnotbeinstalledon
acurbbaseorsealedtothewall.Eitherconditioncan
restricttheowofairtothecombustioncompartment
orpreventproperventilationoftheunit.Beforemaking
anyconnectionstothebroiler,checktheratingsplate
tobesurethebroilerspecicationsconcurwiththe
typeofgasandvoltagetobesuppliedtothebroiler.
Theratingplateislocatedonthebackofthecontrol
compartmentcoverpanelontherightendoftheunit.
Theplatebearingthebroiler’smodelnumberandserial
numberisattachedtothebacksideoftheunit.
Raise or Lower Broiler
Support broiler here
Screw
Screw
Slide Leg.
Reinstall screws.
Plastic Hole Plug
