9 - START UP PROCEDURE
9.15 Parameter Settings
Program boiler electronic board parameters as follows:
• Press and together, hold them down for 6
seconds until program “P01” appears on the display
alternated with the set value;
• Press or to scroll the list of parameters;
• Press , value of selected parameter begins
to change the value;
• Press to exit
without saving.
Further information in regards to parameters listed in the
following table are supplied together with required accessories
if necessary.
9.16 Description Of Parameters: Factory Settings
FACTORY SETTINGS
100,125,165 115,150,205
P01
DHW Fast Modulation
00 =Standard Modulation - on DHW call for heat 10 seconds stabilization time before modulation
01 =Fast Modulation- on DHW call for heat 5 seconds stabilization time before modulation
01
P02
Gas used
00 = Gas A (Natural Gas)
01 = Gas E (LPG Gas)
00
P03
Hydraulic system
00 = instantaneous appliance
03 = instantaneous appliance with pre-heat function
04 = heating only appliance with DHW thermostat
05 = appliance with external storage indirect tank
08 = heating only appliance
13 = instantaneous appliance with pre-heat function for solar application
08 00
P06
00
temperature set-point
01
02…05 = no function is associated
00
Parameters continued on next page
For Natural Gas :
Input (MBH) =
3600 x cu ft
seconds
Meter = 2 cu ft
Measured time = 72 seconds
=
3600 x 2 cu ft
= 100 MBH
72 seconds
For Propane (LP):
Input (MBH) =
9160 x cu ft
seconds
For Metric formulas- See Glossary
2.
Compare measured input to table below. If calculated
again after setting the combustion following steps in
section 9.12.
Input Rate (MBH)
Approximate Rate @
100% Fire (MBH)
Size
100 93.5
115 115
125 125
150 150
165 164
205 205
NOTICE
Important! Record any changes made to Parameters on
chart found on Page 46 of the Application Guide supplied
with your boiler.
Table 9-2 Input Rate @ High Fire (MBH)
P07
00..02 = No function is associated
03 = This is an input contact for CH request (e.g. trigger phone).
When contact CN2 is closed and Room Thermostat (RT) requiring heat switches burner on.
Note: verify heating mode is enabled (winter or heat only mode)
04
E178 anomaly.
Note: verify heating mode is enabled (winter or heat only mode)
05
period.
To enable input it is necessary to set parameter P04 or P05 = 08 and P69 = 05.
Pump will run at P19 minutes (Summer/Winter mode or Only Winter mode) or P19/2 minutes (only Summer mode).
00
P09
Hydraulic Component Setting
Default 01
P10
Heating set-point setting OT / RT (Open Therm / Room Thermostat 120V~)
00 = with Remote Control (RC) connected, temperature request is RC set-point
01 = Temperature Request is highest set point between RC and PCB
02 = Temperature request is RU setpoint. The RT enable the gas boiler operates
00
240013360
REV A [07/01/2021]
