48
PARTS
NO.
DESCRIPTION SECTION QTY
E8302 Glue Tank Tag (1) Frame / Exterior Section 1
E8303 Notching Station Tag (2) Notching Station 1
E8304 Clamp Station Ruler for Binding Width (5) Clamp Station 1
E8305 Glue Level Indicator (3) Glue Tank 1
E8401 Machine Leg (1) Frame / Exterior Section 4
E8402 Cover Ruler (4) Nipping Station 1
E8403 Notching Blade (2) Notching Station 1
E8404 Glue Adjustment Knob (3) Glue Tank 1
E8405 Wiring Hose with Wires (7) Electricity 1
E9001 Sprocket Gear 1 (6) Driving 1
E9002 Nipping Gear 1 (4) Nipping Station 1
E9003 Clamp Transmission Gear 1 (5) Clamp Station 1
U1003 Cover Position Adjustment (4) Nipping Station 2
U2006 Glue Meter (3) Glue Tank 1
U2013 Glue Accumulator (3) Glue Tank 1
U3007A Connecting Collar (2) Notching Station 8
U3009B Notching Base Adjustment Screw (2) Notching Station 3
U4007 Sprocket Shaft 2 (6) Driving 3
U4026 Nipping Position Ring (4) Nipping Station 2
U5001 Clamp Transmission Bearing Seat (5) Clamp Station 4
U5004 Clamp Left Worm (5) Clamp Station 1
U5005 Clamp Right Worm (5) Clamp Station 1
U5006 Clamp Right Worm Seat (5) Clamp Station 1
U5007 Clamp Left Worm Seat (5) Clamp Station 1
U5009 Clamp Right Worm Seat (5) Clamp Station 1
U5010 Clamp Left Worm Seat (5) Clamp Station 1
U6415 Nipping Position Disc (4) Nipping Station 2
U9004 Clamp Chain Wheel (5) Clamp Station 4
U9006 Sprocket Gear 2 (6) Driving 1
U9007 Sprocket Gear 3 (6) Driving 5
U9010 Nipping Gear 2 (4) Nipping Station 3
U9011 Chain (6) Driving 1
U9012 Clamp Transmission Chain (5) Clamp Station 2
U9013 Clamp Transmission Gear 2 (5) Clamp Station 1
Note: The unlisted parts are all durable.
