30
7. OPERATION PROCEDURES
3 For measurement A, press the
“folding plate 1” adjusting button and
move the folding stopper of the first
folding plate to the corresponding
position.
• For measurement B, press the “folding plate 2”
adjusting button and move the folding stopper of
the second folding plate to the corresponding
position.
• When carrying out special folding, folding sizes
should be within the following ranges.
Folding range (A) for first folding plate:
38mm to 325 mm
Folding range (B) for second folding plate:
40mm to 216mm
Max. paper length when folded (C):
216mm
4 Next fix the stopping position of the
stacker rollers.
• Press the (1 to 7) on the keypad with the clear
button held down and move the stacker rollers.
• The stopping position of the stacker rollers
depends on the length of the paper fold.
Refer to the following table “Stacker Roller
Positions” when pressing the keyson the keypad.
Stacker roller
