47
5 Fold the paper as desired and
measure the folded paper. Adjust the
position of the folding stopper of the
folding plate accordingly.
• The figure on the right shows an example of an
accordion fold.
• For measurement A, press the “folding plate 1”
adjusting button and move the folding stopper of
the first folding plate to the corresponding
position.
• For measurement B, press the “folding plate 2”
adjusting button and move the folding stopper of
the second folding plate to the corresponding
position.
• When carrying out special folding, folding sizes
should be within the following ranges.
Folding range (A) for first folding plate:
40 to 325mm
Folding range (B) for second folding plate:
40 to 216mm
Max. paper length when folded (C): 216mm
6 Next fix the stopping position of the
stacker rollers.
• Press the keys (1 to 7) on the keypad to move the
stacker rollers with the clean button held down.
10. USING NON-FIXED PAPER
Accordion fold
