1-51
12H-M12M0-0309-0
3-2-3. Preventing screws from loosening
If the following screws have been removed, apply a very small amount of the specified thread locking.
Set screw of drive gear for automatic up/down of paper feed tray
Set screw of drive gear for stacker roller
Fixing screw of folding pate 2 switching adjusting plate
Specified thread locking: Loctite 242 (Medium strength/for screws)
Fixing screw of slide stopper Z collar
Specified thread locking: Three Bond 1401B (For preventing loosening)
3-2-4. Others
Make sure that no oil and grease adheres to the timing belt and drive pulley grooves.
Fill maintenance data (folded size correction data, etc.) changed during machine adjustments in the backup data
form pasted to the back of the main cover F.
