2-31
12H-M12M0-0309-0
6. PRECAUTIONS ON REPLACING THE MC UNIT
Various data such as home position adjustment data of folding plates and switching shaft and total count memorized
by the unit even when the power has been turned OFF are registered in the EEPROM (nonvolatile memory) of the MC
unit (board). Therefore if the MC unit has been replaced, attach the EEPROM of the old MC board to the new board if
possible.
If board replacement can only be done as a whole together with the EEPROM, note down various settings and total
count data before replacement on the backup data form pasted on the inside of the main cover F, perform the next
step after replacement, and check the data.
(1) Initializing the memory
While pressing the start key, stop key, and clear key together, turn ON the power. This initializes data registered
in the EEPROM of the MC unit. A buzzer sounds three times when the memory is initialized.
(2) Setting various data
Reset data such as home position adjustment data of folding plates and switching shaft in the maintenance mode
as required.
When attaching the EEPROM, take note of the socket direction.
NoteNote
To Next Page
