1-50
12H-M12M0-0309-0
3. PERIODIC INSPECTIONS
3-1. Inspection Points and Procedure
In order to maintain stable paper folding performance and quality, perform periodic inspection every time the machine
has processed 200,000 sheets or every six months, whichever is faster.
Inspection point Inspection Procedure
Paper feed ring,
paper separator
Folding roller
Stacker roller moving
mechanism
Jam correction knob
Paper feed tray automatic up/
down mechanism
Paper feed inlet,
paper ejection outlet sensors
Folding stopper
Folding plate screw shaft
Cleaning
Cleaning
Oiling
Oiling
Greasing,
inspection
Cleaning
Inspection
Cleaning, oiling
Remove paper dust, and clean with alcohol.
Remove paper dust, and clean with alcohol.
Apply oil the sintered bearing.
Apply oil the sintered bearing.
Apply grease the gear surface and rack. (DF-920 only)
Check the wear state of the Z collar.
2-4-2. Cleaning the paper feed inlet sensor
2-5-6. Cleaning the paper ejection outlet
sensor
Check that the fixing screw of the Z collar of the slide
stopper is not loose.
Remove paper dust near the female screw groove on
the screw shaft and the home sensor, and apply a small
amount of oil to the bearing.
The area where the screw shaft and the full nut are
connected cannot be applied with oil or grease.
3-2. Other General Precautions
3-2-1. Oiling
Apply the specified oil to the following locations.
Area where shaft and bearing are connected (sintered bearing)
Specified oil: Orelube G90-140 (Equivalent to ISO #460)
Make sure no oil adhered to the contact surfaces of the armature and rotor of the electromagnetic clutch,
and area where the screw shaft and full nut are connected.
NoteNote
3-2-2. Greasing
Apply the specified grease to the following parts.
Gear teeth, paper feed tray automatic up/down drive rack related parts, etc.
Specified grease: Orelube G1650 (Equivalent to NLGI #1)
Plate spring for grounding conduction of folding roller
Specified grease: Dow Corning MOLY KOTE 41 (Conductive grease)
Make sure no grease adhered to the contact surfaces of the armature and rotor of the electromagnetic
clutch, and area where the screw shaft and full nut are connected.
NoteNote
