* Range of paper length which cannot be corrected to ±0.2". The correction value differs according to the paper length.
10. FOLDING MISALIGNMENT
Correction restrictions
The positions of the folding stoppers of folding plates 1 and 2 may not be adjustable to ±0.2"
according to the length of the paper used. This restriction is due to the length of the paper and
length of folding plates 1 and 2.
The restricted folding plate and correction details differ according to the folding mode and paper
length. Refer to the following table.
LTR +.O3O/ ···
OUT OF CORRECT
If the correction value is within the restricted
range when this correction value is set using
the folding stopper adjusting key, the buzzer
sounds “pi.pi.pi” and the LCD displays “OUT
OF CORRECT”.
The message then changes to “STAND BY”.
Set a valid correction value using the folding
stopper adjusting key.
Double fold
Irregular
accordion fold
Letter fold
Accordion
fold
Brochure fold
Folding
mode
Minimum paper length
that can be used
7.2"
7.2"
5.6"
5.6"
5.1"
Restricted range of
paper length*
7.2" to 8.1"
7.2" to 7.4"
7.2" to 8.1"
5.6" to 6.0"
5.6" to 6.1"
16.8" to 17.0"
16.7" to 17.0"
Restricted folding plate and
correction details
Correction by “–” key of folding plate 2
Correction by “–” key of folding plate 1
Correction by “–” key of folding plate 2
Correction by “–” key of folding plate 2
Correction by “–” key of folding plate 2
Correction by “+” key of folding plate 1
Correction by “+” key of folding plate 2
