Duplo DocuCutter DPC-400 - Tools Tab Configuration; Tool, Speed, and Acceleration Settings

19
TOOL SELECT SPEED ACC
SP1 to SP8: Define the
tool used
- None
- Knife
- Knife1
- Wheel
Knife1 Speed: Maximum speed it can
reach
500 (default)
Knife1 Acc: Acceleration speed of
Knife1
3500 (default)
Cut Speed: Maximum speed of Knife
tool
600 (default)
Cut Accel: Acceleration speed of Knife
3500 (default)
Move Speed: Speed of the Head Unit
in up position
700 (default)
Move Accel: Acceleration speed of
Head Unit
3500 (default)
Cut Down Speed: Knife and Knife1 up
and down speed
100 (default)
Cut Down Accel: Acceleration speed
Up and down motion for Knife and
Knife1 tool
3500(default)
Bending Speed: Control the speed
when making curves
150 (default)
WHEEL TOOL SETTING
