5 | Installation
90
D-R 290
identified as the isolation switch for the device. The individual conductors of the mains
power supply cable must be mutually secured in such a way that they cannot touch
neighbouring terminals whilst being disconnected (e.g. using cable ties).
If monitoring and control of the fail-safe shutter is performed via the measuring head,
the plug end of the 8-core cable already installed should be plugged into the respec
tive panel jack in the measuring head. The free end of the cable is connected to the
respective terminals in the control device of the protective device (D
−SK AE)
(
Fig. 5.23 ).
