0500141 • July 2018
DuraTech InDusTrIes InTernaTIonal Inc.
Po B
ox 1940, JamesTown, nD 58402-1940
T
el: (701) 252-4601• Fax: (701) 252-0502
www.DuraTechInDusTrIes.neT • www.hayBusTer.com
TC-12
Tree Chipper
Manual I: Operating Instructions and Parts Reference
TM
Product InformatIon

Table of Contents

Questions and Answers

  • S
    Suzanne WilliamsAug 16, 2025
    Why does my Duratech Chipper make poor quality chips or not feed properly?
    • A
      Adrian BairdAug 16, 2025
      Your Duratech Chipper might be producing poor quality chips or not feeding properly due to several reasons: * The knives may have lost their edge; file, grind, or replace them. * The knife anvil may be worn or need adjustment; rotate, repair, or replace it. * The knives may be at the wrong angle; use DuraTech knives and sharpen them to a 30-degree angle. * There may not be sufficient feedwheel down pressure; increase the spring tension. * The material being chipped may be small, dry, or rotting, which does not produce good quality chips.
  • D
    Dawn Hunt DDSAug 19, 2025
    What to do if my Duratech Chipper discharge plugs or does not throw chips properly?
    • R
      Rebecca Harrington DDSAug 20, 2025
      If your Duratech Chipper's discharge plugs or it doesn't throw chips properly, it could be due to: * Dull or worn knives, which require sharpening or replacement. * An obstruction in the discharge chute; remove the access cover on the chute to clear the obstruction.
  • J
    jasonhernandezAug 25, 2025
    Why is the feedwheel on my Duratech Chipper slow or stopping when feeding?
    • T
      Tara BeckerAug 25, 2025
      The feedwheel on your Duratech Chipper might be slow or stopping due to: * Dull knives, which need to be replaced or resharpened. * A worn or dirty relief valve, which needs cleaning, resting, or replacement. * A worn pump or motors, both of which need replacement. * Feedwheel springs that are too tight, requiring adjustment.
  • B
    Bradley DiazAug 27, 2025
    How to fix Duratech Chipper bearings running too hot?
    • T
      Troy JacksonAug 27, 2025
      If your Duratech Chipper bearings are running too hot, consider the following: 1. Improper lubrication: Purge bearings once a day with lithium grease. 2. Belt too tight: Set belt tension with a tension gauge. 3. Bearing lock collar loose: Tighten the bearing lock collar set screws. 4. Worn out bearings: Replace the bearings.
  • H
    Heather JonesAug 31, 2025
    What causes the Duratech Chipper knife to hit the anvil?
    • S
      Sara AyersSep 1, 2025
      The chipper knife of your Duratech Chipper might be hitting the anvil because: * The anvil is not set properly; follow the anvil adjustment procedure. * The shaft is misaligned; the disc should have the same clearance side to side, so adjust the pillow block bearing. * The disc is not properly set on the shaft; the disc should have a minimum of 11/16” clearance to the housing on the feed side, so slide the disc on the shaft.
  • S
    Sean TaylorSep 4, 2025
    Why does the chipper disc wobble on my Duratech Chipper?
    • J
      Jessica LewisSep 4, 2025
      The chipper disc on your Duratech Chipper might be wobbling due to: * A loose disc hub; re-torque it to 1620 in-lbs. * A loose bearing; re-torque it to 270 ft-lbs. * Worn chipper bearings; replace them. * A knife pocket or paddle plugged with material; unplug the pockets.
  • A
    Alex SnyderSep 7, 2025
    How to troubleshoot a Duratech Chipper disc that will not turn?
    • A
      Amber ShawSep 7, 2025
      If your Duratech Chipper disc will not turn, it could be due to: * An obstruction in the chipper housing; check the chipper housing and clean it out. * Seized chipper bearings; lubricate or replace them.
  • P
    Paula JohnsonNov 11, 2025
    Why is the feedwheel on my Duratech Chipper turning slowly or not at all?
    • B
      Brenda BarberNov 11, 2025
      There are several reasons why the feedwheel on your Duratech Chipper might be turning slowly or not at all: * The relief valve may be stuck open, in which case you should clean or replace it. * The hydraulic motor or pump may be worn and need replacement. * There might be a pinched hydraulic or damaged hydraulic hose that needs replacing. * The feedwheel valve might be worn and leaking internally, requiring replacement. * The hydraulic oil level may be low, so fill it to at least 7/8 full. * The oil screen may be plugged, so replace it. * There could be binding due to a worn bearing, which requires repair. * The hydraulic oil might be cold, but it should warm up while running. * The speed sensor could be out of adjustment, not working, or the program set points could be ...

Duratech TC-12 Specifications

General IconGeneral
BrandDuratech
ModelTC-12
CategoryChipper
LanguageEnglish
