TC-12 TREE CHIPPER OPERATING INSTRUCTIONS
Spring tensioner for feedwheel
5.9 Spring tensioner for feed wheel
The spring tensioners allow you to adjust the amount of tension on the top feedwheel.
1. Spring tension can be increased by tightening jam nuts on the bottom spring hook assembly.
2. Higher spring tension provides greater grip force.
5.9A Torquing the feed wheel motor nut
Torque tolerance for the feed wheel motor nut is 300-400 ft-lbs (41.5-55.3 m-kg). Torque to 300 ft-lbs (41.5 m-kg) then
tighten until the pin holes line up with the castle nut.
