Duratech TC-12 - Wear Parts

32
TC-12 TREE CHIPPER OPERATING INSTRUCTIONS
Figure 5.4
Discharge Swivel
lubrication point
Discharge swivel
5.7 Wear parts
The feedwheel slide has friction pads and wear pads that will need to be replaced from time to time.
Feedwheel slide arm
Figure 5.5
Feedwheel Slide Arm
