103
ITEM PART QTY. PART DESCRIPTION
TC-12 Tree Chipper PARTS REFERENCE
COVERS (FOR SN 0044 AND UP)
1 4800098 4 BOLT\HEX\3/8X1-1/4\NC
2 4800301 8 SCR\FLNG\SERR\1/4X3/4
3 4800913 19 BOLT\FLG\SERR\3/8X1\NC
4 4900040 10 NUT\FLG\SERR\1/4\NC
5 4900076 17 NUT\FLG\SERR\3/8\NC
6 5000001 4 WASH\FLAT\3/8
7 5000019 4 WASH\LOCK\3/8
8 5000092 2 WASH\LOCK\#8
9 5700202 2 LAMP\GRMMT\2-1/2KIT\W/PLUG
10 5700539 4 LAMP\GRMMT\4-1/2
11 5700723 1 PLC\DVC710
12 5700818 1 LAMP\LIC\KIT
13 5700860 4 LAMP\TAIL\12VDC\4-1/2RD
14 5700861 2 LAMP\CL\12VDC\2-1/2ROUND\RED\SEALED
15 6300140 1 DEFL\SPOUT\DISCH\ASSY
16 6300195 2 COVER\LIGHT\TAIL\R
17 6300256 1 HOOD\RH\TAIL\CHIPPER
18 6300257 1 HOOD\LH\TAIL\CHIPPER
19 6300258 1 BRKT\COVER\VLV
6300002 CHIPPER\ASSY\TC12
