TC-12 Tree Chipper PARTS REFERENCE
ITEM PART QTY. PART DESCRIPTION
1 3701005 1 HOSE\HYD\3/8X28\9/16FJICSX9/16FJIC90
VALVE D TO CYLINDER BOTTOM LIFT
2 3701006 1 HOSE\HYD\3/8X33\9/16FJICSX9/16FJIC90
VALVE C TO CYLINDER TOP LIFT
3 3800453 2 FTG\3/4MORX9/16MJIC\90
4 3800631 2 FTG\9/16MORX9/16MJIC\ST
5 4000403 1 VLV\MANIFOLD\ASSY\CHIPPER
6 4100262 1 CYL\HYD\2X12\1-1/4TUBE
HYDRAULIC CYLINDER ASSEMBLY
