Teile-Nr./ Part-No.:
0791 867772
Printed in Federal Republic of Germany
Ausgabe/Edition:
03.2007
Blatt: 5 von 16
Sheet from
4. Verschleissteileliste
Pos. Bestell-Nr. Benennung
0667 156054 Spulengehäuse komplett
1 0667 156060 Spulengehäuse
2 0767 150714 Deckel k omplett
3 0992 023577 (3x) Li. Senkschraube
4 0992 023560 Li. Senkschraube
5 0992 023560 Li. Senkschraube
6 0767 150640 Niederhalter
Umbauanleitung für Bobbinengreifer CLB 300
Instructions for converting bobbin hook CLB 300
867 190342
34
6
2
5
1
