DUSK ISLA - IS 翻盖储物柜 ISL-TAU-HDDK 说明书 英文注释版241225 Model (1)

Page 11
Step 11
Step 12
2
3
6
13
1
A
4pcs
E
2pcs
F
2pcs
J
1pc
G
2pcs
G
F
F
G
A
A
A
A
E
E
J
Put the board 13 into
cabinet as shown.
Fix cam bolt into board(A) as shown.
Fix magnetic catch(J) to the board 1 with screw(E)
as shown.
Fix L wall fixing(F) with screw(G) as shown.
