DUSK ISLA - IS 翻盖储物柜 ISL-TAU-HDDK 说明书 英文注释版241225 Model (1)

Page 6
Step 1
Step 2
B
2pcs
C
4pcs
T
2pcs
A
5pcs
A
A
A
A
A
4
7
4
5
5
B
B
T
T
C
C
C
C
B
Fix cam bolt(A) to the board 4 and board 7 as shown.
Attach board 5 to the board 4 with
wooden dowel(C),put the cam(B) into
board 5 then turn clockwise to tighten
as shown,stick the cam hole with
sticker(T).
