DUSK ISLA - IS 翻盖储物柜 ISL-TAU-HDDK 说明书 英文注释版241225 Model (1)

Page 4
Fittings check list
Please check you have all the fittings listed below with your product:
A
Bolt Length Ruler:
Tool required
Crosshead Screwdriver (not provided)
0 1
cm
3
4 5
6
7
8 9 10 11 12 13 14 15 16 17 182
36mm cam bolt x19pcs
（ ）
+2 extra
B
M15x9.5mm cam x19pcs
（ ）
+2 extra C M6x30mm Wood dowel x24pcs
（ ）
+2 extra
D
M4x35mm Screw x10pcs
（ ）
+1 extra
E
M3x14mm Screw x43pcs
（ ）
+3 extra
F
L wall fixing x2pcs
G
M4x12mm Screw x2pcs
H
30mm Wall Plug x2pcs
I
M4x30mm Screw x6pcs
J
K
M6x55mm Screw x4pcs
L Metal plate x4pcs
M
Metal plate x4pcs
N
L fitting x1pc O
Felt pad x4pcs
P
Back bracket x12pcs
（ ）
+1 extra
Q
R
S T
Sticker x19pcs
（ ）
+2 extra
U
Metal plate x1pc
Magnetic Catch x1pc
Handle x3pcs Hinge x4pcs
M4x14mm Screw x24pcs
（ ）
+2 extra
