‘CSC300’ Controller (cont’d)
Unit Standard Operating Parameters.
The chart below indicates the standard operating parameters programmed into the ‘CSC300’ Controller at the
factory.
HP
Control
Mode
Target
Pressure
Offload
Pressure
High
Pressure
Alarm
High
Pressure
Shutdown
Idle
Shutdown
(minutes)
Routine
Service
Hours
Grease
Service
Hours
20
Load/
Offload
100 psi
(6.9 bar)
120 psi
(8.3 bar)
125 psi
(8.6 bar)
130 psi
(9.0 bar)
10 2000 2000
25
Load/
Offload
100 psi
(6.9 bar)
120 psi
(8.3 bar)
125 psi
(8.6 bar)
130 psi
(9.0 bar)
10 2000 2000
25
Variable
Speed
110 psi
(7.6 bar)
120 psi
(8.3 bar)
125 psi
(8.6 bar)
130 psi
(9.0 bar)
2 2000 2000
30
Load/
Offload
100 psi
(6.9 bar)
120 psi
(8.3 bar)
125 psi
(8.6 bar)
130 psi
(9.0 bar)
10 2000 2000
30
Variable
Speed
110 psi
(7.6 bar)
120 psi
(8.3 bar)
125 psi
(8.6 bar)
130 psi
(9.0 bar)
2 2000 2000
A description of the terminology used in the above chart is as follows:
HP: Horsepower of the Unit.
Target Pressure: The pressure at which the Unit will try to maintain.
Offload Pressure: The pressure at which the Unit will stop compressing air.
High Pressure Alarm: The pressure (above the Offload Pressure) at which an alarm will be noted.
High Pressure Shutdown: The pressure (above the Offload Pressure) at which an alarm will be noted and the
Unit will shut off.
Idle Shutdown: The amount of time the Unit will idle (run but not compress air) after it has reached the Unload
Pressure before shutting off.
Routine Service Hours: The maximum allowable time between regular maintenance/service of the Unit.
Grease Service Hours: The maximum allowable time between motor lubrications.
The above chart is supplied for information only. Serious consequences could result should any of the
parameters be adjusted by someone who is not familiar with the correct and safe operation of the Unit.
Any adjustments made to the above parameters by others (other than a qualified Technician) resulting in the
incorrect operation of the Unit, damage to the Unit, or damage to property is not covered by the DV Systems
Warranty.
Please consult with your DV Systems Distributor or contact DV Systems directly should you have any
questions or concerns about any of the information in the chart above, or in this manual.
