DV Systems G20 Maintenance And Service Data

G2030-II-S
Apr ‘19
- 9 -
Maintenance Procedures
Changing the Air / Oil
Separator.
1) If necessary, use a strap wrench to
turn the original Separator counter-
clockwise.
2) On the new ‘DSC-001148’ Air / Oil
Separator, lubricate the Separator
Gasket with Compressor Oil.
3) Hand tighten the new Air / Oil
Separator snug
Note:
Do not over-tighten the Separator
Filter on the Unit, as it may become
very difficult to remove at a later date.
Changing the Air Intake Filter.
1) Loosen the Filter Clamp at the base of the
Intake Filter.
2) Remove the Air Filter Element from the Unit.
3) Clean the Intake Valve area of any dust or
build-up.
4) Install a new Air Filter (DV Systems Part
Number ‘DSC-001961’), ensure it fits snugly on
the Intake Valve Assembly, and tighten the
Filter Clamp.
Note:
Depending on the quality of the air in the
compressor room, it may be necessary to check
and/or change the Air Filter more often than
indicated on the 'Maintenance Schedule'.
Changing the Oil Filter.
The Oil Filter should be changed only after all of
the oil has been drained from the Unit.
1. Ensure that you have a bucket and strap
wrench available.
2. Holding the bucket under the original Oil
Filter to capture any spillage, use the strap
wrench to turn the Oil Filter counter-
clockwise. The Oil Filter may still contain oil,
so care must be taken.
3. On the replacement ‘DSC-624’ Oil Filter,
lubricate the Filter Gasket with Compressor
Oil.
4. Hand tighten the Oil Filter snug.
